Import FutureBoard Library
Import the Library to make use of its functions.
| from future import * |
04: Turtle
1. Setting the Pen Color
| turtle.fillcolor(color) |
Turtle accepts RGB value for color, value range is 0~255. Example: (255,100,0)
2. Moving the Pen Forward
| turtle.forward(steps) |
Moves the pen forward by the number of steps.
3. Turning the Pen
| turtle.left(angle) turtle.right(angle) |
Turns the pen to the left or right by the degree of angle.
4. Setting the Heading
| turtle.setheading(angle) |
Sets the heading to be the angle.
5. Moves the Pen to a Point
| turtle.goto(x,y) |
Moves the pen to a point (x,y).
6. Moves the Pen along an axis
| turtle.setx(x) turtle.sety(y) |
Moves the pen to a point on the x or y axis.
7. Draws a Dot
| turtle.dot(d) |
Draws a dot with the diameter of d.
8. Draws a Circle
| turtle.circle(r,angle) |
Draws an arc with the given radius and angle, a 360 degree arc results in a full circle.
9. Sets a Fill Area
| turtle.begin_fill() turtle.end_fill() |
Begins and ends the fill area.
Note: The screen of the FutureBoard is below the requirements for the Turtle MicroPython Library, there may be unintended results with the fill function.
10. Sets the Pen Up or Down
| turtle.pendown() turtle.penup() |
11. Clears the Screen
| turtle.clear() |
Sample Program
|
from future import * |
If you have any question, please feel free to contact us at Discord, we will always be there to help.
KittenBot Team
